Product Name | Bus, Incandescent, Red, Rectangular, 1 Bulb, Stop/Turn/Tail, 4 Screw, Blade Terminal, 24V |
---|---|
Brand | TL |
Category | Stop/Turn/Tail |
Warranty | 1-Year |
Compliance Family | FMVSS 108|CMVSS 108|DOT|SAE |
Country of Origin | ZZ |
Current Minor | .48 |
Diamond Shell (Yes/No) | No |
Features & Benefits | 12V lamps mate with PE Connector 6288471|Recess mounts using two screws at 30" centers and two screws at 42" centers|Watertight lamp mates withPackard connector |
Feature Highlights | No Plug|24 V |
Itm Id | 2034394 |
KIT (Yes/No) | No |
Lens Shape | Rectangular |
Lighting Technology | Incandescent |
Lamp Connection | Blade Terminal |
Lens Color | Red |
Lens Height_INH | 5.2 |
Lens Material | Polycarbonate |
Lens Width_INH | 6.46 |
Mount Type | 4 Screw |
Number of Diodes/Bulbs | 1 |
Packaging Type | Standard |
Part Number | 07092-4 |
Plug Side One | No Plug |
Plug Side Two | No Plug |
Reflectorized (Yes/No) | No |
Sealed/Bulb Replaceable | Sealed |
Standards Met | I6|P|S2|T2 |
Std Carton Qty | 1 |
Taxonomy | Lights.Stop/Turn/Tail Lights |
Total Depth_MMT | 51.56 |
Total Depth | 2.03 |
Temp. Description | Rectangular Tail 24 Volt-Speci |
Total Height_MMT | 132.59 |
Total Height | 5.22 |
Total Length | 2.1 |
Total Width_MMT | 164.08 |
Total Width | 6.46 |
UNSPSC/Tariff | 25172900 |
UPC | 0735111009559 |
VMRS | 017-009-015 |
Voltage (VLT) | 24 |
Weight | 1 |
