Product Name | 44 Series, LED, Yellow Round, 1 Diode, Rear Turn Signal, Black Flange Mount, Hardwired, .180 Bullet, 12-24V |
---|---|
Brand | TL |
Category | Turn Signal |
Series | 44 Series |
Warranty | 3-Year |
Country of Origin | ZZ |
Current Minor | .06 |
Features & Benefits | Electronics completely sealed in epoxy to resist moisture and corrosion|Lamp hardwired - wire leads incorporate 180 jacketed bullet terminals|Sealed polycarbonate lens and housing|Voltage range:OmniVolt 10v to 30v |
Feature Highlights | Hardwired|.180 Bullet |
Housing Material | Polycarbonate |
Itm Id | 2910577 |
KIT (Yes/No) | No |
Lens Shape | Round |
Lighting Technology | LED |
Lamp Connection | Hardwired |
Lens Color | Yellow |
Lens Height_INH | 4.31 |
Lens Material | Polycarbonate |
Lens Width_INH | 4.31 |
Mount/Trim Color | Black |
Mount/Trim Material | Polycarbonate |
Mount Type | Flange Mount |
NAPA Part Number | 44938Y |
Number of Diodes/Bulbs | 1 |
Number of Wires | 3 |
Packaging Type | Standard |
Part Number | 44938Y4 |
Plug Side One | Hardwired |
Plug Side Two | .180 Bullet |
Position | Rear |
Reflectorized (Yes/No) | No |
Sealed/Bulb Replaceable | Sealed |
Standards Met | E13 |
Std Carton Qty | 1 |
Taxonomy | Lights.Turn Signal Lights |
Total Depth_MMT | 44.45 |
Total Depth | 1.75 |
Total Height_MMT | 139.7 |
Total Height | 5.5 |
Total Length | .16 |
Total Width_MMT | 139.7 |
Total Width | 5.5 |
UNSPSC/Tariff | 25172900 |
UPC | 0735111185789 |
VMRS | 034-002-041 |
Voltage (VLT) | 12|24 |
Weight | .2 |
